806-4422

44 Series Setscrew Yoke

44 series yoke with round with 2 keyways bore and setscrew connection

View My List

PTO drive shafts end with an implement yoke, it is the final connection between the PTO drive shaft and the machine or implement connected to the tractor. Weasler implement yokes are provided in a variety of bore and mounting options. Bore options include square, rectangle, hexagon, round and spline. Standard yoke connection options are set screws and pins. Additional implement yoke connection options include torque limiter flage yokes, telescoping yokes (square, round, and hexagon), and clamp yokes.

PERFORMANCE BENEFITS

Specifications

Spec. Imperial Metric
Bore 11.37 inches35 mm
Bore 1 ROUND WITH 2 KEYWAYS
Connection 1 SETSCREW
Height4.50 inches114 mm
HP@1000RPM158 HP118 kilowatts
HP@540RPM103 HP77 kilowatts
Keyway 10.38 inches10 mm
Keyway 20.25 inches6 mm
Length4.62 inches117 mm
Shipping Dimensions5.56" L  ×  4.5" H  ×  2.5" W14cm L  ×  11cm H  ×  6cm W
Shipping Volume62.55 in31025 cm3
Shipping Weight4.58 pounds2 kilograms
Weight4.58 pounds2 kilograms
Width2.50 inches64 mm

Downloads

Document Name Type Language
Service Instructions - Lubricating PTO Drive Shaft.pdf Maintenance Document English
Service Instructions - Universal Joint.pdf Service Document English
Lack of Grease - Cross & Brg Kit.pdf Troubleshooting Document English
