807-3527

35 Series Clamp Yoke

35 series yoke with 1 3/4-27 spline bore and clamp connection

View My List

The clamp yoke allows for a tight connection to a mating shaft to minimize fretting corrosion and wear, using standard hardware.

PERFORMANCE BENEFITS

Specifications

Spec. Imperial Metric
Bore 11.75 inches44 mm
Bore 1 1 3/4-27 SPLINE
Connection 1 CLAMP
Height4.00 inches102 mm
HP@1000RPM108 HP81 kilowatts
HP@540RPM70 HP52 kilowatts
Length5.30 inches135 mm
Shipping Dimensions6.18" L  ×  4" H  ×  3.28" W16cm L  ×  10cm H  ×  8cm W
Shipping Volume81.08 in31329 cm3
Shipping Weight5.00 pounds2 kilograms
Weight5.00 pounds2 kilograms
Width3.28 inches83 mm

Downloads

Document Name Type Language
Service Instructions - Lubricating PTO Drive Shaft.pdf Maintenance Document English
Service Instructions - Universal Joint.pdf Service Document English
Lack of Grease - Cross & Brg Kit.pdf Troubleshooting Document English
Check out the new Aftermarket Make / Model Driveline FinderDOWNLOAD HERE
