204-6580
E EXTENDED LUBE, CUP GREASE FITTINGAB5 Series Cross And Bearing Kit
AB5 series cross and bearing kit, e extended lube, cup grease fitting
E-kits provide increased capacity and extended lubrication intervals with a lube cycle of 50 – 250 hours. This is achieved by providing an improved seal and roller bearings design, which results in a longer life cycle. E-Kits are interchangeable with other cross and bearing kits in Weasler series as well as standard cross and bearing sets in the market. This means that a Weasler PTO drive shaft with E-kits can still be upgraded to M-kits.
PERFORMANCE BENEFITS
Extended lubrication cycle of 50 to 250 hours.
Interchangeable with standard cross and bearing kits available in the market.
Easier grease access through the guard, no need to remove guard.
Higher torque capacity and longer life reduces downtime – avoid costly cross and bearing kit replacements.
DESIGN FEATURES
Larger roller bearings for added durability in demanding applications.
High temperature, triple lipped seal keeps grease in and contaminants out.
A bright orange seal with grease fitting makes it fast and easy to find an E-Kit.
E-Kits are interchangeable with all standard cross and bearing kits and available for all series. Plus – standard kits can easily be upgraded to E-Kits.
Manufactured with high quality steel for increased strength.
Specifications
Spec. | Imperial | Metric |
---|---|---|
Bearing Diameter | 1.18 inches | 30 mm |
Bearing Span | 3.12 inches | 79 mm |
Bearing Diameter | 1.18 inches | 30 mm |
Bearing Span | 3.12 inches | 79 mm |
Height | 1.18 inches | 30 mm |
HP@1000RPM | 100 HP | 75 kilowatts |
HP@540RPM | 65 HP | 48 kilowatts |
Kit Type | E | |
Length | 3.12 inches | 79 mm |
Lubrication Interval | 50.00 | |
Shipping Dimensions | 3.122" L × 1.189" H × 3.122" W | 8cm L × 3cm H × 8cm W |
Shipping Volume | 11.59 in3 | 190 cm3 |
Shipping Weight | 1.36 pounds | 1 kilograms |
Snap Ring Location | External | |
Weight | 1.36 pounds | 1 kilograms |
Width | 3.12 inches | 79 mm |
Downloads
Document Name | Type | Language |
---|---|---|
Service-Instructions-Lubricating-PTO-Drive-Shaft.pdf | Maintenance Document | English |
Service Instructions - Universal Joint.pdf | Service Document | English |
WE0101007_0118_USL_EKit.pdf | Performance Benefits Document | English |
