17003527
UNIVERSAL JOINT AND TUBE35 Series Universal Joint And Tube
35 series universal joint and tube with 1 3/8-6 spline, quick disconnect connection and 1 3/16 square, telescoping connection
The Weasler Cardan type Universal Joints are robust, engineered and produced for high power density and long life. Produced to exact tolerances they provide for simple, easy service and tight bearing fits. The universal joints can be used alone, or as a component of a drive shaft system. Tubing is available in both domestic (North American) and metric profile shapes. Domestic tubing is provided as square, rectangle, or round. Slip sleeves available in square and spline design. The Weasler Profile product line includes metric tubing available in both German and Italian styling: German style provided as lemon or star in shape and Italian as trilobed in shape.
PERFORMANCE BENEFITS
Specifications
| Spec. | Imperial | Metric |
|---|---|---|
| Bore 1 | 1.37 inches | 35 mm |
| Bore 1 | 1 3/8-6 SPLINE | |
| Bore 2 | 1.19 inches | 30 mm |
| Bore 2 | 1 3/16 SQUARE | |
| Compressed (Closed) Length | 21.88 inches | 556 mm |
| Compressed Overall Length | 26.57 inches | 675 mm |
| Connection 1 | QUICK DISCONNECT | |
| Connection 2 | TELESCOPING | |
| HP@1000RPM | 79 HP | 59 kilowatts |
| HP@540RPM | 51 HP | 38 kilowatts |
| Length | 26.57 inches | 675 mm |
| Shipping Dimensions | 26.57" L × 4" H × 4" W | 67cm L × 10cm H × 10cm W |
| Shipping Volume | 425.12 in3 | 6966 cm3 |
| Shipping Weight | 0.00 pounds | 0 kilograms |
| Weight | 0.00 pounds | 0 kilograms |
Downloads
| Document Name | Type | Language |
|---|---|---|
| Service-Instructions-Lubricating-PTO-Drive-Shaft.pdf | Maintenance Document | English |
| Service Instructions - Universal Joint.pdf | Service Document | English |
| Lack of Grease - Cross & Brg Kit.pdf | Troubleshooting Document | English |
| WE0101011_0817_USL_EasyLockGuard.pdf | Performance Benefits Document | English |
