Easy Lock Guard Half
Multiple series easy lock guard half
Guard halves are one half of the entire guard set. Guard halves will either include the implement half or the tractor half of the set, and will not cover an entire PTO drive shaft. Weasler guard halves are interchangeable with other Weasler guard halves, it will not interchange with other guard halves in the market.All Weasler guards are designed according to ANSI/ASABE AD5673 and meet strength and wear requirements of ANSI/ASABE AD 5674. Guards can be certified to CE requirements as an option.
Easy Lock system allows for quick and easy assembly without tools; A simple tool such as a key, coin or screwdrive can be used to remove the guard.
Easy Lock clip includes a zerk for ease of lubrication.
Easier lubrication of the PTO drive shaft through grease access holes so the guard does not need to be removed for lubrication.
Black guard color is durable against ultraviolet light and ozone.
Easy Lock Guard System: Provides full coverage at maximum angles.
Full 360° friction weld on guard bell.
Black coloring that is durable against ultraviolet light and ozone.
Cold weather impact rated to -35°C.
Meets and exceeds all applicable safety standards.
Quick and easy process for removal and installation.
|Length||30.00 inches||762 mm|
|Outside Diameter||7.28 inches||185 mm|
|Shipping Dimensions||30" L × 7.28" H × 7.28" W||76cm L × 18cm H × 18cm W|
|Shipping Volume||385.83 in3||6323 cm3|
|Shipping Weight||0.00 pounds||0 kilograms|
|Tube Size||3.25 inches||83 mm|
|Weight||0.00 pounds||0 kilograms|
|Service Instructions - Lubricating PTO Drive Shaft.pdf||Maintenance Document||English|
|Service Instructions - Easy Lock Guards.pdf||Service Document||English|
|WE0101011_0817_USL_EasyLockGuard.pdf||Performance Benefits Document||English|
