Part Number: 301-1400
SHAFT WELD YOKE
14 Series Weld Yoke
14 series yoke with 1 5/16-20 spline bore and weld connection
Region Availability: North America, South America
Weasler yoke weldment assemblies provide yoke to shaft and yoke to tube weldment options that are offered in both North American (domestic) , German, and Italian shaft and tube shapes.
PERFORMANCE BENEFITS
Specifications
Part Number: 301-1400
Product Series: 14
| Spec. | Imperial | Metric |
|---|---|---|
| Bearing Diameter (Ear Hole) | 1.13 (1 1/8) in | 29 mm |
| Bearing Cap to Cap Span | 2.63 (2 5/8) in | 67 mm |
| Bore Description | 1 5/16-20 SPLINE | |
| Connection 1 Type | WELD | |
| HP@1000RPM | 58 HP | 43 kilowatts |
| HP@540RPM | 38 HP | 28 kilowatts |
| Centerline to End Dim | 3.37 (3 3/8) in | 86 mm |
| Weight | 2.02 pounds | 1 kilograms |
| Bore 1 | 1.37 (1 3/8) in | 35 mm |
| Bore Description | 1 5/16-20 SPLINE | |
Downloads
| Document Name | Type | Language |
|---|---|---|
| Service-Instructions-Lubricating-PTO-Drive-Shaft | Maintenance Document | English |
| Service-Instructions-Universal-Joint | Service Document | English |
| Lack-of-Grease-Cross-Brg-Kit | Troubleshooting Document | English |
